Technical Characteristics:
Power supply: 2 size”C” Alkaline Batteries
Warm-Up Time: 6 seconds
Application of refrigerant:
Detect leaks in other systems and storage/recovery containers. It will respond to all halogenated (including Chlorine of Fluorine)refrigerants. This includes but is not limited to:
CFCs e.g. R12, R11, R500, R503 etc
HCFCS e.g. R22, R123, R124, R502 etc
HFCS e.g. R134a, R404a, R125 etc
Blends such as Az-50. HP62 MP39 etc
Detect Ethylene Oxide gas leaks in hospital sterilizing equipment (it will detect the halogenated carrier gas)
Detect SF-6 high voltage circuit breakers
Detect most gages that contain chlorine, Fluorine and Bromine(halogen gases)
Detect cleaning agents used in dry cleaning applications such as perchloroethylene.
Sensitivity: 3g/yr of R-134a(ultimate Sensitivity); 6 g/yr of R-134a(max sensitivity)
Battery Life: 50 hours, under typical intermittent operation
Probe: Flexible gooseneck, 14 inch
Visual and Audible indicators:
Power & Battery: Tri-color LEd display (according to the glowing sequence of color: red, green, and orange)
Relative Leak Level: 7 levels of increasing LED display
Visual -7 LEDs progressively glow from left to right when halogen level Increases
Audible- Beep-sound, rate change along with the visual LED, increase from its idle rate to a higher frequency when higher levels of halogen are detected
Operating Environment:
Temperature: 0°C to 52°C
Humidity: 20 to 80% RH, non-condensing
The forward direction air flue supplied by mechanical pump improves and enhances the detection sensitivity.
